DAMP PROOF COURSE & BRICKWORK PRODUCTS

Visqueen Zedex CPT DPC

High Performance Damp Proof Course (DPC) is manufactured from co-polymer thermoplastic (CPT) providing all the characteristics necessary for it to perform effectively for the lifetime of the building in which it is incorporated. Excellent performance under high compressive loads . Zedex jointing tape ( 100mm ) and Zedex Fixing strip are used with this DPC system.

Visqueen Zedex Data Sheet

Visqueen Preformed Cavity Tray Units

An integral part of the Zedex High Performance Damp Proofing System, the Visqueen range of standard preformed cavity tray units simplify detailing at corners, changes of level, etc. They reduce the time required on site to install a DPC cavity tray and eliminate the likelihood of water ingress at these complex, awkward junctions. Visqueen PFU Data Sheet

Please call for information.

Polythene/Plastic  DPC

Polythene/Plastic D.P.C. is manufactured to approved British Standards Requirements for the composition, finish and impermeability of Polythene Damp Proof Course for use in masonry construction . Applications  :   Near to ground level as a moisture barrier ,  To close cavities at openings in brickwork , In parapets, to prevent downward water penetration,  Beneath sills and coping made of porous material ,

Ruberoid Hyload Original  DPC

Trusted for over 50 years, IKO Hyload Original is the UK’s leading High Performance DPC. Suitable for damp proofing and cavity trays in all solid/cavity wall applications (brick, block, stonework and concrete), it is resistant to compression even under the heaviest of wall loading and won’t extrude under load.

Features and Benefits - BBA approved (Certificate no. 95/3133) - Over 50 years’ proven reliability - Excellent performance under high compressive loads - Good flexibility at low temperatures - Market leading mortar adhesion - Tough and durable - Available in a wide range of size - Complementary preformed cloaks available - Contains over 70% recycled materials .

Hyload Original Data Sheet

Ruberoid Hyload Trade DPC

IKO Hyload Trade is a polymeric DPC material suitable for use as a DPC and cavity tray system for all types of construction including house building, commercial, industrial and multi storey. Hyload Trade DPC uses the same proven technology as used with Hyload Original DPC, which was the first system of its kind in the UK and was awarded the first ever Agrément Certificate in 1967.

IKO Hyload Trade  conforms to the requirements of ground gas protection measures designed to the NHBC traffic light system, and CIRIA C665. The product currently does not conform to the requirements of ground gas protection measures designed to BS8485:2015.

Hyload Trade Data Sheet

Ruberoid Permabit DPC

Permabit has long been the DPC of choice for many brickwork contractors, offering excellent performance in terms of tensile, elongation and tear strength. It provides horizontal, vertical or stepped DPCs including cavity trays in solid/cavity walls of brick, block, stone or concrete. A mixture of bitumen, synthetic polymers, synthetic fibres and other additives, Permabit excels where mortar adhesion is particularly important, for example in lightly loaded areas .

Permabit DPC Data Sheet

Hyload Preformed Cloaks & Cavity Trays

Hyload preformed cloak units simplify the damp proofing of awkward junctions and eliminate leakage paths. They also enable swift installation, saving potential problems and costly remedial works on site. For complex architectural details, Hyload special cloaks can be provided from bespoke drawings through to on site delivery. Lift Pit Cloaks are also available as Special Cloaks through Ruberoid’s dedicated structural waterproofing technical services team.

Hyload Preformed Cloaks Data Sheet

RIW Sheetseal 9000 DPC

RIW Sheetseal 9000 is a key product in our range of high quality polymeric damp proof course materials. Based on a composition of Ethylene Propylene rubbers and polyester fibres which increases the tensile strength and elongation at break making the system more resistant to tearing and puncturing. RIW Sheetseal 9000’s strength, flexibility and workability provides an efficient method of controlling water penetration within a building.

Hyload Insulated DPC

Hyload Insulated DPC (previously Ruberclose) has been developed to minimise cold bridging when closing masonry cavity walls around openings. Designed to be installed as work proceeds, it is easy to handle and resilient enough to accommodate irregularities in cavity closers.

Hyload Insulated DPC Data Sheet

Damcor & Hyload Insulating Vertical DPC

Damcor 165mm & 225mm x 6 mt rolls

A complete and simple solution to thermal bridging where the cavity is closed. Combining advantages of expanded Polystyrene and Polyethylene DPC, DAMCOR is designed to prevent the problem of cold bridging around window and door openings in traditional cavity constructions.

SCS Thermalstop Insulated Economy DPC

SCS Insulated DPC 165mm & 225mm - 6 / 10 mt rolls

We stock 6mt & 10mt Rolls of 165mm and 225mm  Thermal Stop Insulated DPC. Used to provide insulation and damp proofing between the inner brickwork and outer blockwork to prevent damp and help eliminate mould growth. Our 10 metre rolls are GWP & ODP zero rated , so compatable with central London green targets.

Visqueen Gas Resistant DPC

Visqueen Gas Resistant (GR) Damp Proof Course is a flexible polyethylene DPC with an aluminium foil designed to prevent the transmission of carbon dioxide, radon, methane and low level hydrocarbon vapours. This is in addition to the product’s usage as a damp proof course. Resistance to harmful gases is achieved by an integral aluminium film. Visqueen GR DPC Data Sheet

Visqueen Ultimate/HC Blok Units

These units are made to order , though we do have a few standard sizes in stock .

Visqueen Preformed units ( PFUs ) are factory manufactured three dimensional shapes . The unts are formed from either Zedex CPT High Performance DPC  ( Zedex Units ) or Visqueen Ultimate HC Blok ( Ultimaye Units ).

The units are highly versatile , BBA approved and suitable for damp and gas proofing applications.

Visqueen Zedex Hi Bond DPC

Visqueen Hi Bond DPC is available from us in various widths . This product is made from aluminium, bonded to tough polyester, which is then coated with modified bitumen (asphalt) and silica sand to finish. Obviously, it is a very tough, heavy duty material. This product has an improved adhesion to concrete and is able to be torch bonded. It is particularly suitable for cavity tray applications and is able to bear loading of walls of up to three storeys. It also has some gas protection as it has low permeability to methane gas. Visqueen Hi Bond Data Sheet

RIW Gas Seal GR DPC

RIW Gas Seal GR DPC   is a Damp Proof Course , Cavity Tray suitable for use in masonary where resistance to Carbon Monoxide , Methane and Hydrocarbon is required.

The product must be lapped and sealed to the gas proof membrane internally as neccesary. Preformed RIW Gas Seal GR Cloaks can be prefabricated for use in external & Internal corners and door reveals. RIW Gas Seal DPC Data Sheet

Brick Mesh Coils

20 metre rolls    65/115/175/305mm

Expanded metal brickwork reinforcement is embedded in mortar joints (usually every third course) to give extra tensile strength to wall and help withstand vibration and sudden loading, or to minimize unsightly cracks due to settlement. The material is galvanized or stainless steel and normally finished in 20 meter coils.

Cavity Wall Ties  / Frame Cramps

Light Duty ( Type 4 )     General Purpose ( Type 2 )    Heavy Duty ( Type 1 )

Wall ties, sometimes called 'brick ties', are used in buildings with cavity walls. They are used to join the two leaves of a cavity wall together, allowing the two parts to act as a homogeneous unit. Hidden from view after construction, wall ties play a vital role in ensuring the stability of a building.

Brickspan Masonary Reinforcement

MSF Masonry Reinforcement, also known as Brickspan, Brickforce and Bed Joint Reinforcement is primarily used to strengthen walls, Stainless Steel can be used on both inner and external bricks/blocks whereas galvanised is more suited to internal walls. Our Masonry Reinforcement aids to reduce cracking within walls and structures, as well as providing general support.

Helifix Crack Stitching

MSF Masonry Reinforcement, also known as Brickspan, Brickforce and Bed Joint Reinforcement is primarily used to strengthen walls, Stainless Steel can be used on both inner and external bricks/blocks whereas galvanised is more suited to internal walls. Our Masonry Reinforcement aids to reduce cracking within walls and structures, as well as providing general support. Helifix Data Sheet

Thermabate Cavity Closers

The Thermabate insulated cavity closer provides a simple and efficient method of closing cavities around openings in masonry walls. The insulating foam core prevents thermal bridging, while the PVC-U box section forms a positive damp proof barrier and key for the direct application of plaster. It effectively prevents condensation, pattern staining and mould growth frequently associated with traditional methods of closing cavities

30 metre packs  50mm - 100mm  ( 10 x 3 mt lengths)

SCS Cavity Closers

The SCS Cavity Closer has been designed to provide an easy and effective way of closing the cavities within openings in masonry walls for windows and doors.

The Cavity Closer acts as a seal preventing external water vapour and damp from entering the cavity wall and the building , while also preventing heat from being lost through the gap.

24 metre packs 50mm - 125mm   ( 10 x 2.4 mt lengths )

Airbricks &  Telescopic Vents

The Airbrick has been designed to provide high levels of ventilation into cavity walls and under floor voids.  The brick incorporates a front mounted grille with water deflectors. A mortar key around the edge of the airbrick ensures it can be securely fixed to the building fabric and a clip together facility provides a choice of ventilation sizes.

The Telescopic Underfloor Void Ventilator is designed to provide a clear airflow passage to the void underneath a suspended floor.The telescopic feature enables the ventilator to adjust vertically between three and five brick courses. The right airflow can be achieved when the ventilator is used with an Airbrick.

 Weep Vents

The Weep Vent is used to drain lintels, cavity trays and to ventilate cavity walls. The product can be slotted between two bricks and mortared into position. It provides an unobtrusive ventilation point for the cavity behind. The vent has a baffled grille to prevent the ingress of driving rain and wind whilst incorporating an insect grille and drip lip. This grille is sized to keep out large insects but is wide enough that it will not be blocked by debris, paint or water droplets.
